Installing led wall lamps and assembly instructions

The decoration of led wall lamps and lanterns refers to the evidence that can be used for decoration and lighting, usually, this type of lighting is mainly composed of artistic lamps, with different shapes and aspects, beautiful, elegant, and generous, the following will introduce the installation methods of wall lamps related to content.

The installation method of led wall lamps, what is the specific installation method?
1. Led Wall lamp: According to the structure of the base, the led wall lamp can be with or without a base. When using the base, secure the base before attaching the wall light to the base. The base is usually made of wood, the thickness of the board should be more than 15 mm, and the surface is painted with decorative paint. It can be fastened by screwing the threaded holes in the box light location, or perforating the wall surface, previously introducing wooden bricks or fixing it with threaded plastic expansion pipes. The screws of the led wall lamp base are generally not less than two. The installation height of the wall lamp is usually 2 to 2.3 meters from the ground, and the led wall lamp installed on the bed is preferably 1.2 to 1.4 meters.

2. Downlights: Downlights are embedded lights, suitable for ceilings. The basic shape of the lamp is cylindrical, and the mouth of the led wall lamp is a wide lead, titanium or nickel plated metal ring. With the light installed, it is close to the top surface and is beautifully decorated. On each side of the lamp's symmetry there is a safety ring as a means of securing the downlight. The opening is oriented towards the opening of the lamp, and the separation of the safety ring is adjusted by a wing nut.

3. Pendant lamp: When the lamp is installed on the upper surface of the concrete, it can be fixed with inserts, penetration bolts and expansion bolts. The size and weight of the lighting equipment used in the installation depends on the specifications of the expansion bolts used, but the small size should be larger than M6 (mm), the chandelier should not be smaller than M8 (mm) and the number of nails must be at least two. Lightweight self-tapping screws cannot be used.

4. The base of the ceiling lamp can be fixed with expansion bolts, or with wood screws pre-installed with wood screws. If the base of the lamp holder exceeds 100 mm in diameter, 2 screws must be used. If lampholders are installed, bolts and penetration bolts must be used, and the diameter of the bolts must be not less than 6 mm. The light fixture can be fastened to the lower part of the platform with wood screws. The number of wood screws shall not be less than the number of mounting holes provided by the luminaire.

The above introduces the relevant content of the installation method of led wall lamps. There are many types of lamps. EJLED believes that lamps and other furniture need regular maintenance.
